Pump unit

Product Introduction:

The F-1300/1600 pump unit has the characteristics of compact structure, complete functions, reliable use, and convenient testing.

Structure Description

The F-1600 pump set is composed of F-1600 pumps. Narrow V-belt pulley, DC motor, base, shield, safety valve hydraulic circuit, and electric spray pump system.

Two branch motors pass through 2 × 4ZV5J+1 × 5ZV25J narrow V-belt driven mud pump. The DC motor base can be adjusted on the pump base to tension the belt. The pump unit is also equipped with a rotatable cantilever crane for use when replacing vulnerable parts or repairing the hydraulic end of the mud pump.

Prepare fully enclosed belt guards on both sides.
